SM-15 HD
SM Series
A higher degree of flexibility, enhanced performance and low environmental impact are some of the key points featuring our best selling micropiling rig new design.
The SM-15HD is equipped with a larger and more powerful Diesel engine for heavy duty works and a special undercarriage to increase performance in anchoring technology and Jet Grouting. The SM-15HD is particularly suitable to drill when using the double-head system.
| Dato | Unità di misura | Valore |
|---|---|---|
| Diesel engine T3/Stage V | kW | 186/179 |
| Max Torque | daNm | 1207-3390 |
| Weight | t | 19 |
| Boom articulation | type | 3 different options |
| Clamping range | mm | 50-315 / 60-415 |
| Feed stroke | 4000-7000 | |
| Max feed force | 121 | |
| Max hoist | kN | 121 |
| Track shoe width | mm | 400 |
