STM-30
STM Series
STM-30 is a drill unit designed to be fast, highly productive and easy to operate. It’s a fully hydraulic drilling rig mounted on standard, heavy duty 6 x 4 truck. Thanks to its power, reliability and new configuration, the STM-30 meets with the needs for a high performance and easy to mobilize drilling rig.
The application is:
| Dato | Unità di misura | Valore |
|---|---|---|
| Max Torque | daNm | 130 |
| Weight | t | 29 |
| Diesel engine | kW | 164 |
| Max depth | m | 55 |
| Max diameter | mm | 1500/2200 |
| Dato | Unità di misura | Valore |
|---|---|---|
| Max depth (LDP) | m | 55 |
| Max Diameter (LDP) CCS/WCS | mm | 1500/2200 |
