SM-25: Productivity Driven Performance
The brand new Soilmec SM-25 has been engineered to maximize productivity in micropiling, anchoring and jet grouting applications. Combining up to 140 kN pullback and crowd force</strong> with a high-speed rotary system, it delivers fast drilling cycles and outstanding operational efficiency.
Optimized working geometry, excellent mast kinematics and rapid positioning capabilities allow operators to spend more time drilling and less time setting up and relocating the machine.
Designed around the balance of force, drilling speed and operational efficiency, the SM-25 helps contractors maximize daily production, reduce non-productive time and increase overall jobsite performance.
| Dato | Unità di misura | Valore |
|---|---|---|
| Diesel engine T3/Stage V | kW | 209 |
| Weight | t | 25 |
| Boom articulation | type | Slewing |
| Clamping range | mm | 60-415 |
| Feed stroke | mm | 10300 |
| Max feed force | kN | 140 |
| Max hoist | kN | 140 |
| Max Torque (daNm) | daNm | 2100 |
