  Diesel engine T3/T4
kW
Weight
t
Max torque
kNm

SR-30
Advanced
164/168 34 130
SR-40
Evolution
180/- 47 161
SR-45
Advanced
201/201 37-38 185
SR-60
Evolution
261/- 60 201
SR-75
Advanced
328/328 70 290
SR-80
Evolution
328/- 80 271
SR-95
High-Tech
403/403 90 351
SR-125
High-Tech
470/470 128 435
SR-145
High-Tech
470/470 145 435
  Diesel engine
kW
Weight
t
Max torque
kNm

STM-20
119 20 85
STM-30
164 29 130
Piling Rigs
Hydraulic drilling rigs optimally designed to give you the best drilling performance.
SR-30

Soilmec rigs are self-mounting, easily transportable and designed to giving the best drilling solutions.
The hydraulic drilling rig SR-30 has been specially designed for suiting the following applications:

- LDP cased bore piles with casing driven directly by rotary head;
- LDP deep uncased bored piles stabilized by drilling fluid or dry hole;

SR-40

Soilmec rigs are self-mounting, easily transportable and designed to giving the best drilling solutions.
The hydraulic drilling rig SR-40 has been specially designed for suiting the following applications:

- LDP cased bore piles with casing driven directly by rotary head or optionally by casing oscillator powered by the base carrier itself;
- LDP deep uncased bored piles stabilized by drilling fluid or dry hole;

SR-45

Soilmec rigs are self-mounting, easily transportable and designed to giving the best drilling solutions.
The hydraulic drilling rig SR-45 has been specially designed for suiting the following applications:

- LDP cased bore piles with casing driven directly by rotary head or optionally by casing oscillator powered by the base carrier itself;
- LDP deep uncased bored piles stabilized by drilling fluid or dry hole;

SR-60

Soilmec rigs are self-mounting, easily transportable and designed to giving the best drilling solutions.
The hydraulic drilling rig SR-60 has been specially designed for suiting the following applications:

- LDP cased bore piles with casing driven directly by rotary head or optionally by casing oscillator powered by the base carrier itself;
- LDP deep uncased bored piles stabilized by drilling fluid or dry hole;

SR-75

Soilmec rigs are self-mounting, easily transportable and designed to giving the best drilling solutions.
The hydraulic drilling rig SR-75 has been specially designed for suiting the following applications:

- LDP cased bore piles with casing driven directly by rotary head or optionally by casing oscillator powered by the base carrier itself;
- LDP deep uncased bored piles stabilized by drilling fluid or dry hole;

SR-80

Soilmec rigs are self-mounting, easily transportable and designed to giving the best drilling solutions.
The hydraulic drilling rig SR-80 has been specially designed for suiting the following applications:

- LDP cased bore piles with casing driven directly by rotary head or optionally by casing oscillator powered by the base carrier itself;
- LDP deep uncased bored piles stabilized by drilling fluid or dry hole;

SR-95

Soilmec rigs are self-mounting, easily transportable and designed to giving the best drilling solutions.
The hydraulic drilling rig SR-95 has been specially designed for suiting the following applications:

- LDP cased bore piles with casing driven directly by rotary head or optionally by casing oscillator powered by the base carrier itself;
- LDP deep uncased bored piles stabilized by drilling fluid or dry hole;

SR-125

Soilmec rigs are self-mounting, easily transportable and designed to giving the best drilling solutions.
The hydraulic drilling rig SR-125 has been specially designed for suiting the following applications:

- LDP cased bore piles with casing driven directly by rotary head or optionally by casing oscillator powered by the base carrier itself;
- LDP deep uncased bored piles stabilized by drilling fluid or dry hole;

SR-145

Soilmec rigs are self-mounting, easily transportable and designed to giving the best drilling solutions.
The hydraulic drilling rig SR-145 has been specially designed for suiting the following applications:

- LDP cased bore piles with casing driven directly by rotary head or optionally by casing oscillator powered by the base carrier itself;
- LDP deep uncased bored piles stabilized by drilling fluid or dry hole;

STM-20

STM-20 is a drill unit designed to be fast, highly productive and easy to operate. It's a fully hydraulic drilling rig mounted on standard, heavy duty truck.  Thanks to its power, reliability, and novel configuration STM-20 meets the needs for a highly capable, easily mobilized drilling rig.

STM-30
STM-30 is a drill unit designed to be fast, highly productive and easy to operate. It's a fully hydraulic drilling rig mounted on standard, heavy duty 6 x 4 truck. Thanks to its power, reliability and new configuration, the STM-30 meets with the needs for a high performance and easy to mobilize drilling rig.
  Diesel engine
kW
Weight
t
Max torque
kNm

SF-50
164 39 100
SF-65
205 52 165
SF-120
350 100 300
CFA
Compact hydraulic drilling rigs specially designed for continuous flight auger piles technology.
SF-50

The SF-50 drilling rig, is the evolution of the already existing equipment dedicated to Continuous Flight Auger drilling technique.
The upper structure of the SF-50 is mounted on Soilmec base carrier and has been designed to perform:

- CFA (Continuous Flight Auger) piles by means of long auger string.

SF-65

The SF-65 drilling rig, is the evolution of the already existing equipment dedicated to Continuous Flight Auger drilling technique.
The upper structure of the SF-65 is mounted on Soilmec base carrier and has been designed to perform:

- CFA (Continuous Flight Auger) piles by means of long auger string.

SF-120

The SF-120 drilling rig, is the evolution of the already existing equipment dedicated to Continuous Flight Auger drilling technique.
The upper structure of the SF-120 is mounted on Soilmec base carrier and has been designed to perform:

- CFA (Continuous Flight Auger) piles by means of long auger string;
- CAP (Cased Augered Piles) piles with double independent rotary system.

  Diesel engine
kW
Winch line pull
kN
Weight
t

SC-50 HD
201 150 49
SC-70 HD
403 260 70
SC-80
205 178 74
SC-90 HD
470 297 93
SC-120 HD
522 376 131
Cranes
Heavy duty hydraulic crawler cranes for different foundation technologies.
SC-50 HD

SC-50 HD is a Soilmec crane with an hydraulic proportional control system that provides accurate and simultaneous movements. Regarding performance, the maximum capacity is 50 tons with a working radius of about 3.6 m; the diesel engine power (201 kW) and the hoisting force (150 kN) are greater than those of the main competitors’ cranes.

SC-70 HD

SC-70 HD is a Soilmec crane with an electro-hydraulic proportional control system that provides accurate and simultaneous movements. Regarding performance, the maximum capacity is 72.6 tons with a working radius of about 3.3 m; the diesel engine power (403 kW) and the hoisting force (260 kN) are greater than those of the main competitors’ cranes.

SC-80

SC-80 is a Soilmec crane with an electro-hydraulic proportional control system that provides accurate and simultaneous movements. Regarding performance, the maximum capacity is 80 tons with a working radius of about 3.5 m; the diesel engine power (205 kW) and the hoisting force (178 kN) are greater than those of the main competitors’ cranes.

SC-90 HD

SC-90 HD is a Soilmec crane with an electro-hydraulic proportional control system that provides accurate and simultaneous movements. Regarding performance, the maximum capacity is 90 tons with a working radius of about 3.6 m; the diesel engine power (470 kW) and the hoisting force (297 kN) are greater than those of the main competitors’ cranes.

SC-120 HD

The SC-120 HD crawler mounted crane has been designed meeting the advantage of being dedicated and multifunctional at the same time. It can be used to work with hydromills, crane attachments, vibrators, hydraulic and mechanical grabs, etc.

  Cutting depth
m
Diesel engine
kW
Weight
t

SC-100
Cougar
52 563 100
SC-120
Cougar
57/63 653 135
SC-135 HD
Tiger
100/120 (150*) 653 135
SC-200 c/w P450/P700
Tiger
250 450 200
  Panel thickness
mm
Panel width
mm
Body lenght
m

SH-30
700/1200 2600/3000 10.5
SH-40
800/1800 2800/3200 13
SH-50
1000/2000 2800/3200 14.7
  Max depth
m
Excavation dimension (width x length)
mm
Weight
t

BH-8
75 (60 m on request) 350/800 x 2000/3200 8
BH-12
75 (60 m on request) 500/1200 x 2000/3500 12
GH-12
75 500/1200 x 2500/4200 12,5
GH-15
75 600/1500 x 2800/4200 15,2
GC-11
depending on the crane 600/1200 x 2500/3000 11,3 (600x2500)
GC-16
depending on the crane 800/1200 x 2800/3500 16 (800x2800)
Hydromill & Grabs

Hydromills with hose wheel and drum hose design for deep diaphragm walls.

Mechanical cable operated and hydraulic grabs for diaphragm wall technology.

SC-100

The demand for diaphragm wall equipment suitable to urban areas and the stringent requirement of verticality make the hydromill Cougar a good and easy option to meet the customer’s needs.

The Hose Wheels Design (HWD) is positioned below the cathead so that it can easily follow the hydromill movements with a tensioning and rewinding automatic system. It arises from the need to move simultaneously the hydraulic and bentonite mud circulation hoses to the cutting unit.

The SC-100 Cougar is a compact hydromill equipment optimized for urban areas and low transportation weight (max 50 t; 110,000 lb).

SC-120

The demand for diaphragm wall equipment suitable to urban areas and the stringent requirement of verticality make the hydromill Cougar a good and easy option to meet the customer’s needs.

The Hose Wheels Design (HWD) is positioned below the cathead so that it can easily follow the hydromill movements with a tensioning and rewinding automatic system. It arises from the need to move simultaneously the hydraulic and bentonite mud circulation hoses to the cutting unit.

The SC-120 Cougar is the high performance HWD series, which excavates more than 60 m of depth with approx. 900 HP ensuring a great level of production rates.

SC-135 HD

With the aim of meeting the need for increased diaphragm wall depth in the most challenging soil conditions, Soilmec has designed the “HDD” (Hose Drums Design) hydromill configuration. Hydraulic and mud winders are positioned on a base carrier, allowing high depth drilling performances.

SC-200 c/w P450/P700

The SC-200 Tiger is the hydromill which allowed to excavate the deepest diaphragm wall in the world (250 m depth). The record was achieved in 2012 with a proofed verticality deviation of about 0.1%.

SH-30

The hydromill module is constituted by a heavy steel frame on which two milling drums and a centrifugal mud pump are mounted. In order to correct the module verticality deviation, 12 independent mobile flaps are positioned on the module surface. Furthermore, a simultaneous or independent tilting plate can be installed as optional for the best verticality correction, especially in case of leaned layers of rock. All Soilmec modules are set with a 2D or 3D sensor developed for the module positioning control, which is managed by the Hydromill DMS.

SH-40

The hydromill module is constituted by a heavy steel frame on which two milling drums and a centrifugal mud pump are mounted. In order to correct the module verticality deviation, 12 independent mobile flaps are positioned on the module surface.

Furthermore, a simultaneous or independent tilting plate can be installed as optional for the best verticality correction, especially in case of leaned layers of rock. All Soilmec modules are set with a 2D or 3D sensor developed for the module positioning control, which is managed by the Hydromill DMS.

Soilmec has designed all its modules with a rotation system conceived for T-panel execution or for other module orientations. This specific feature gives the possibility to facilitate the job site operations, leading to a reduction in terms of cost and time.

The 40 t class module is suggested for medium-high depth projects. Its body length and weight guarantee a high verticality level and panel dimensions up to 3200x1800 mm. The high torque cutting unit (up to 153 kNm) can be installed.

The module rotation system is included as a standard.

SH-50

The hydromill module is constituted by a heavy steel frame on which two milling drums and a centrifugal mud pump are mounted. In order to correct the module verticality deviation, 12 independent mobile flaps are positioned on the module surface.

Furthermore, a simultaneous or independent tilting plate can be installed as optional for the best verticality correction, especially in case of leaned layers of rock. All Soilmec modules are set with a 2D or 3D sensor developed for the module positioning control which is managed by the Hydromill DMS.

Soilmec has designed all its modules with a rotation system conceived for T-panel execution or for other module orientations. This specific feature gives the possibility to facilitate the job site operations, leading to a reduction in terms of cost and time.

The 50 t class module is conceived for special projects. Its body length and weight guarantee a high verticality level and panel dimensions up to 3200x2000 mm in different soil conditions and at the highest depths (up to 250 m).

The module rotation system is included as a standard.

BH-8

The Soilmec hydraulic grabs are the result of years of research and development in mechanical excavation. The collection of data from various sites, tests on different soil types, the study of the performance of difficult soft soils and layers allowed the production of the series of hydraulic grabs more competitive available on the market.

They can operate in any soil type coarse or cohesive. In the presence of large boulders or hard conglomerate formations, we recommend the traditional chiseling.



BH-12

The Soilmec hydraulic grabs are the result of years of research and development in mechanical excavation. The collection of data from various sites, tests on different soil types, the study of the performance of difficult soft soils and layers allowed the production of the series of hydraulic grabs more competitive available on the market.

They can operate in any soil type coarse or cohesive. In the presence of large boulders or hard conglomerate formations, we recommend the traditional chiseling.

GH-12

The Soilmec hydraulic grabs are the result of years of research and development in mechanical excavation. The collection of data from various sites, tests on different soil types, the study of the performance of difficult soft soils and layers allowed the production of the series of hydraulic grabs more competitive available on the market.

They can operate in any soil type coarse or cohesive. In the presence of large boulders or hard conglomerate formations, we recommend the traditional chiseling.

GH-15

The Soilmec hydraulic grabs are the result of years of research and development in mechanical excavation. The collection of data from various sites, tests on different soil types, the study of the performance of difficult soft soils and layers allowed the production of the series of hydraulic grabs more competitive available on the market.

They can operate in any soil type coarse or cohesive. In the presence of large boulders or hard conglomerate formations, we recommend the traditional chiseling.

GC-11

GC serial mechanical grabs are rope suspended and rope operated. Side guides and jaws are interchangeable in order to perform different panel sizes with the same grab body.

GC-16

GC serial mechanical grabs are rope suspended and rope operated. Side guides and jaws are interchangeable in order to perform different panel sizes with the same grab body.

  Max diameter
mm
Max depth
m
Max torque
kNm

RT3-ST
3000 80 210
SA-40
4000 94 413
Attachment rigs
Diesel and hydraulic crane attachment rigs for large diameter bored piles.
RT3-ST

RT3-ST model allows to drill holes of diameters from 600 to 2500 mm to various depths up to 80 m.

SA-40
Hydraulic crane attachment for large diameter bored piles to be combined with hydraulic Soilmec cranes.

- Max nominal torque: 413 kNm
- Max depth: 90 m
- Max diameter: 4000 mm
  Diesel engine
kW
Max hoist
kN
Weight
t

SM-4
115 70 5.8
SM-5
75 40 5.6
SM-9
105 60 9.3-9.5
SM-10
116 70 10.5-12.5
SM-14
119 89 14
SM-17
160 100 17/19
SM-18
176 113 19
SM-22
194 140 22
SM-28
194 170 33-38.8
  Diesel engine
kW
Max hoist
kN
Weight
t

SM-10GT
119 120 13
SM-16GT
176 200 15-17
  Diesel engine
kW
Max hoist
kN
Weight
t

SM-8G
85 100 8,9
SM-16G
176 195 16,7
  Diesel engine
kW
Max hoist
kN
Weight
t

ST-20
123 + (90) 67 21
ST-60
135 + (116) 70 60
ST-120
164 + (2x90) 84 119
Microdrilling

Hydraulic drilling rigs designed to perform microipiles, anchors, water wells, corings, consolidations with jet grouting, soil investigation and geothermal applications.

Hydraulic rigs for sub-horizontal consolidations of large section tunnels.

SM-4

SM-4 is a new drilling machine featuring a separate power pack and the same movements of its larger sister, the SM-5. It has two different engine sizes available: 115 kW and 110 kW respectively (diesel and electrical).

SM-5

The new SM-5 is a compact drill rig weighting 5.6 tons, available both with a combined kinematic mechanism that includes a telescopic arm, a +/- 90° tilting and a slew ring on mast (standard version), and in the G version that features a fixed kinematic mechanism and coring rotary, for soil-investigation.
The significant installed power, 72 kW, achieves high performance despite small dimensions, thanks to a wide rotary selection with torque values ranging between 690 daNm and 2100 daNm.



SM-9

The SM-9 is a multipurpose drilling rig. Its modular design is engineered for the execution of:  micropiles, tie-backs, jet-grouting, coring, drain, water wells. The rig is fitted with proportional, hydraulic servo-assisted controls that make the operations smooth and trouble free even in the hardest working conditions.

SM-10

The SM-10 is a multipurpose drilling rig. Its modular design is engineered for the execution of:  micropiles, tie-backs, jet-grouting, coring, drain, water wells. The rig is fitted with proportional, hydraulic servo-assisted controls that make the operations smooth and trouble free even in the hardest working conditions.

SM-14

Soilmec SM-14 is a multipurpose drilling rig. Its modular design is engineered for the execution of:
Micropiles, Tie-backs, Jet-grouting, Drain, Water wells.
The rig is fitted with proportional, hydraulic servo-assisted controls that make the operations smooth. Featured with Load Sensing System, it has lower running costs and a reduced wear and tear on components.

SM-17

Soilmec SM-17 is a multipurpose drilling rig developed from the fusion of TREVI GROUP job-site experience and SOILMEC technological research, thus perfectly responding to the needs of professionals worldwide.
Its modular design is engineered for the execution of: Micropiles, Tie-backs, Anchors, Jet Grouting and Mini-piles.

SM-18

Soilmec SM-18 is a multipurpose drilling rig developed from the fusion of TREVI GROUP job-site experience and SOILMEC technological research, thus perfectly responding to the needs of professionals worldwide.
Its modular design is engineered for the execution of: Micropiles, Tie-backs, Anchors, Jet Grouting and Mini-piles.

SM-22

The new SM-22 is an evolution of the historic PSM-1350 and SM-20 models and have been completely redesigned to ensure high efficiency and productivity levels on site together with the highest safety standards.

SM-28

The SM-28 is a multipurpose rig that suits a wide range of civil engineering work requirements. High standard components and advanced hydraulic circuit design have enabled increased rig performance, preserving its reliability, even under extreme conditions. Its smart and compact de-sign allows fast rig assem-bly and ease of transport (even in a container). Minimum operating costs.

SM-10GT

The new SM-10GT is a hydraulic drilling rig designed specifically for geothermal drilling.

The fixed kinematic mechanism, wide section mast, and the pull-push system with a 120 kN hydraulic cylinder means drilling deep, precise bores.

The rubber tracked undercarriage and low specific pressure on the ground make this machine ideal for operating in gardens and private courtyards, typical in this kind of application, reducing the impact of the site.

SM-16GT

SM-16GT responds to the demand of geothermal systems drilling between 100 and 250 metres.
The equipment's characteristics mean it can satisfy 70% of demand from the low-enthalpy geothermal sector. The compact drilling rig has a rubber tracked, 2300 mm-wide carriage and very low ground bearing pressure (0.65 Kg/cm2), thereby minimising damage to private property (gardens and courtyards) where domestic geothermal energy is used.

SM-8G

Designed mainly for geognostic use, it can be used for vertical drilling micropiles or inclined ± 13°.
Main features:
- Rotation head with 6 ratio gearbox
- Fixed kinetic mechanism

SM-16G

Specific equipment for Soil Investigation, designed for deep core drilling.
The high pull/push values and the high hydraulic power installed lets you use fast rotary speeds (over 1000 rpm) for conventional and wire-line diamond core drilling to great depths.

Main features:
- Rotary head with 6-speed transmission (maximum speed: 1000 rpm)
- Fixed kinematic mechanism
- Extraction capacity: 19500 kg
- Hydraulic balancing

ST-20

The ST-20 tunnelling rig is ideal for sub-horizontal consolidation in tunnels with a work radius of between 1512 mm and 4696 mm (with the drilling mast horizontal at 0°). The useful stroke of the rotary allows treatments of up to 14 m (16 with the optional extension).
The drilling mast can be folded in at both ends, reducing the overall dimensions, to make the rig easier to transport both underground and on the road at the end of the job.

The machine has two motors (diesel and electric) of a suitable size for each single motor to perform all the drilling, traversing and positioning operations of the crawler.

ST-60

ST-60 tunnelling rig project was developed to meet the growing need for sub-horizontal consolidation in large-section tunnels using single-boom equipment working with the full section method as an excellent alternative to the double-boom type system traditionally used for this type of job.
The equipment is very flexible and fast to use, also in relation to the importance of the treatments to perform. To reach the maximum heading stroke points with respect to ground level, a special system of thrust blocks and sliding blocks was designed to reach these points in total safety. The machine has a mast for 19000 mm treatments in one pass and 24000 m treatments with matching chuck and optional extensions.

The maximum extension height at 0° with respect to ground level is 10700 mm.
The variability of the height of the thrust block axis of rotation from 850 mm to 4250 mm combined with the column extension allows a work radius of from 3700 mm to 6500 mm. Tunnel lining is over 180°.
Fitted with two motors (diesel and electric) for both drilling and traversing, guaranteeing performance also in case of a breakdown of one of the two units.

ST-120

The ST-120 tunnelling rig is the top of the Soilmec tunnelling range.
Designed for the consolidation of large section tunnels it can be used for treatments up to a maximum of 21000 mm in one pass and 24000 mm with matching chuck. Heights of 10100 mm can be reached at the heading with the arms perfectly horizontal at 0°.

The main feature of the ST-120 positioner is the geometry of the two cradles that house the system of sliding blocks and telescopic arms, letting you work far from the face to consolidate (12000 mm) guaranteeing the greatest safety in operations underground. Furthermore, each of the single drilling arms is fully independent, driven by two separated power and remote control units.

The weight of the rig in operational layout, depending on the optional devices fitted and the configuration used, is between 110 and 120 tonnes.

Ancillaries
Highly performing auxiliary equipment and accessories dedicated to the use of bentonite and slurry and to the preparation and injectionof water/cement mix.
Mud Line

Soilmec offer a machine, a technology and a solution to meet foundation needs. A comprehensive and technologically advanced jobsite, enriched by IPC technology with highly performing auxiliary equipment and accessories in a Mud product line dedicated to the use of bentonite and slurry.

Grout line

Soimec offer a machine, a technology and a solution to meet foundation needs. A comprehensive and technologically advanced jobsite, enriched by IPC technology with highly performing auxiliary equipment and accessories in a Grout product line dedicated to the preparation and injection of water/cement mix.

Drilling tools
Selecting the correct cutting tool is a complicate decision that any piling contractor will face on every job in order to complete it on time and, therefore, the use of an appropriate tool capable of achieving the overall expected productivity level is vital.
Controls
Electronic devices and instruments dedicated to machine monitoring, data logging, production and fuel consumption, GPS guiding systems and drilling positioning.
Drilling Mate System

DMS - Drilling Mate System - is a project born in the mid-90s with the aim of providing to both operator and jobsite personnel, an active instrument to control and interact with the machine (sensors, safety devices, diesel engine, drilling parameters, etc.).

APS

APS (Automatic Positioning System) is a GPS guidance system that integrates in real-time he topography positioning coordinates and the dialing control parameters of each machine.

DPS

The DPS (Drilling Positioning System) was developed in order to control the drilling positions, before executing jet grouting columns.
This control is of basic importance in the execution of bottom plugs and deep waterproofing shields.

News & Journal
The new SR-125 HIT at work in Cesena (Italy) for the new OROGEL 3 Plant
The new Soilmec SR-125 HIT drilling rig in CFA configuration worked hard in the jobsite located in Cesena. The project involves building three new production departments, one refrigerated warehouse and two cold stores 30 metres high.
Events
Join our newsletter
About us

LEADING GROUND ENGINEERING FOR 40 YEARS

Soilmec is an international company leader in design, manufacture, and distribution of equipment for the ground engineering industry.
The company was established in 1969 by entrepreneur Mr. Davide Trevisani as Pali Trevisani (today known as Trevi S.p.A.). Since its inception, Soilmec has always developed safe, innovative, cutting-edge technologies and provided the construction industry the full spectrum of equipment solutions.

Soilmec equipment is used everyday on jobsites all around the world for bridges, viaducts, motorways, tunnels, underground lines, railways and buildings of all types.


Foundations Technology Academy
Trevi innovation started about fifty years ago, by a bunch of men who knew about the foundation engineering and believed in the future.
They researched and had the world as horizon. They won and became one of the most remarkable groups in the foundation field at worldwide level.
I cookie ci aiutano a fornire i nostri servizi. Utilizzando tali servizi, accetti l'utilizzo dei cookie da parte nostra. Info
